Fire Extinguisher Modular Valve

1.00

Fire Extinguisher Modular Valve designed for automatic modular type fire extinguishers, ensuring reliable pressure control and effective fire suppression.

Fire Extinguisher Modular Valve
Fire Extinguisher Modular Valve
1.00

Modular Valve

The Modular Valve is a critical component engineered specifically for modular type fire extinguishers. It enables controlled and efficient release of extinguishing agents upon fire detection, ensuring the system activates without manual intervention. Constructed from high-quality brass or stainless steel (variant-dependent), this valve ensures longevity, leak-proof performance, and safety in both commercial and industrial fire protection systems.
Technical Specifications
  • Type: Modular Fire Extinguisher Control Valve

  • Material: Brass / Stainless Steel

  • Application: For Clean Agent / ABC / CO₂ / other modular extinguishers

  • Mechanism: Pressure-activated valve with thermal sensor integration

  • Thread Size: Standard BSP threading (as per model specification)

  • Operating Pressure: 12–18 bar

  • Operating Temperature: -20°C to +55°C

  • Compatibility: Ceiling-mounted modular type extinguishers

  • Finish: Corrosion-resistant coating or polished finish

  • Compliance: IS standards / CE Certified (depending on variant)

  • Automatic activation in response to heat

  • Durable construction for extended service life

  • Leak-proof and corrosion-resistant design

  • Easy to install and replace

  • Compatible with multiple extinguishing agents

  • Supports both refillable and disposable units

  • Server Rooms and Data Centers

  • Electrical Panels and Control Rooms

  • Warehouses and Storage Areas

  • Manufacturing Units and Workshops

  • Commercial Complexes and High-Risk Zones

  • Information Technology and Data Management

  • Power and Electrical Infrastructure

  • Manufacturing and Warehousing

  • Hospitality and Commercial Buildings

  • Transportation Facilities

  • Packaging: Individually boxed with sealing cap

  • Delivery Time: 3–7 working days based on availability

  • Warranty: Manufacturer’s warranty applicable (subject to model)

Ensure valve compatibility with your extinguisher type and model. Regular inspection and servicing are recommended for optimal performance.
