MS Elbow C Class Heavy – Durable and Reliable Elbow for Piping Systems
Technical Specifications
Material: Mild Steel (MS) for strength, durability, and corrosion resistance
Size Options: Available in sizes including 25 mm, 32 mm, 40 mm, 50 mm, 65 mm, 80 mm, 100 mm, 150 mm, and 200 mm
Pressure Rating: Suitable for heavy-duty and high-pressure systems
Temperature Range: Designed for applications ranging from -20°C to 120°C
Finish: Available with painted or galvanized finish for enhanced corrosion resistance
Angle: Typically 90-degree elbow for efficient flow direction change
Compliance: Meets ISO 9001 and ANSI standards for elbow fittings
Features and Benefits
Durable Construction: Made from high-strength mild steel (MS), the elbow can withstand high pressure and harsh environments, ensuring long-term durability
Heavy-Duty Design: The C Class Heavy Elbow is ideal for heavy-duty applications such as chemical processing, industrial piping, and HVAC systems
Corrosion Resistant: Galvanized or painted finish provides additional corrosion resistance, making it suitable for moist and aggressive environments
Leak-Proof Performance: The tight fit ensures that the elbow provides a secure connection that prevents leaks in the piping system
Efficient Flow Control: The 90-degree angle allows for smooth flow direction changes while minimizing flow resistance
Versatile Applications: Perfect for use in water distribution, oil & gas pipelines, HVAC systems, and industrial manufacturing
Easy Installation: Available with welded or flanged ends for seamless integration into existing piping systems
Applications and Use Cases
Industrial piping systems for precise flow direction changes in high-pressure applications
Chemical processing to redirect corrosive liquids or gases safely and efficiently
Water distribution systems for seamless flow control in municipal and commercial systems
HVAC systems to manage cooling and heating systems and airflow in commercial buildings
Plumbing systems in homes and industrial sites for securing water or gas lines
Oil & gas pipelines for flow redirection in fluid transport systems
Suitable Industry Types
Plumbing & HVAC
Water Treatment & Distribution
Chemical & Petrochemical
Oil & Gas
Manufacturing & Industrial Processing
Packaging and Delivery
Packaging: Securely packed to prevent damage during transport
Delivery: Within 3–5 working days from order confirmation
Bulk Order Support: Custom packaging and branding available for bulk orders
Usage Note
Ensure the MS Elbow C Class Heavy is installed securely and that all fittings are properly tightened to avoid any leakage or system inefficiency. Regularly inspect for wear and corrosion, particularly in high-pressure or chemical systems. Free delivery and installation are available within a 10 km radius from our service center.
